223CSP

22 AWG 3 conductor 7 strands tinned copper wire, polyethylene insulation, shielded, with an overall PVC jacket.
SKU: 223CSP


• UL listed as type CM c(UL)us 75°C per UL standard 444
• UL recognized component as type AWM 2093 per UL standard 758
• UL approved for Sunlight Resistant Applications
• Cable meets RoHS 2002/95/EC Directive, RoHS 2 2011/65/EU Directive, RoHS 3 2015/863/EU Directive
• Cable is REACH compliant per Regulation (EC) No 1907/2006 (211) Updated January 19, 2021
• Operating Voltage: 300V RMS
• Made in the USA

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.
Products specifications
Attribute nameAttribute value
Conductor
AWG Size & Stranding22 AWG 7 Strands Class B
MaterialAnnealed Tinned Copper
Conductor Count3 Conductors
Insulation
MaterialPolyethylene
Wall Thickness0.016”
Color CodeBlack, Clear, Red
Assembly
GroundN/A
FillersN/A
BinderN/A
ShieldAluminum/Mylar Tape- 100% coverage
Drain Wire22 AWG 7 Strands Tinned Copper
Jacket
MaterialPolyvinylchloride
Wall Thickness0.033”
Diameter0.197” ± 0.020"
ColorChrome Gray
RipcordYes
Cold Bend RatingN/A
Weight23 Lbs/Mft
Markings
TypeCable permanently identified via surface inkjet print
LegendLAKE CABLE E171202 22AWG 3C 75C C(UL)US CM OR AWM 2093 300V 60C “ROHS COMPLIANT” MADE IN USA
Footage MarkersYes
