25 AWG RGB video snake composite cables with an overall PVC jacket. UL CMR c(UL)us 75ºC 300V for miniature component video cable for permanent installations
25 AWG RGB video snake composite cables with an overall PVC jacket. UL CMR c(UL)us 75ºC 300V for miniature component video cable for permanent installations
25 AWG RGBHV video snake composite cables with an overall PVC jacket. UL CMR c(UL)us 75ºC 300V for miniature component video cable for permanent installations
25 AWG RGBHVC video snake composite cables with an overall PVC jacket. UL CMR c(UL)us 75ºC 300V for miniature component video cable for permanent installations
One Cat5E and 25 AWG RGBHVC video snake composite cable with a TPE jacket for miniature component video cable
8 Element composite cable with an overall PVC jacket. UL CMR c(UL)us 75ºC 300V for miniature component video cable for permanent installations
18 AWG solid copper covered steel conductor with foam FEP insulation, an aluminum/mylar heat fusible an aluminum braid shield, an aluminum/mylar/aluminum shield, an aluminum braid and an overall plenum rated PVC jacket for CATV, Satellite, Broadband and MATV applications
20 AWG RG59/U constructed with solid bare copper, foamed PE insulation, a bare copper braid shield and an overall PVC jacket. CL2R OR CMR 75’C FT-4 Surveillance Camera cable applications
18 AWG solid copper covered steel conductor with foam PE insulation, an aluminum/mylar heat Fusible tape with an aluminum braid shield and an overall PVC jacket for CATV, Satellite, Broadband and MATV applications 1. Conductor 1.1. AWG & Stranding: 18 AWG Solid 1.2. Material: Copper Covered Steel
18 AWG solid copper covered steel conductor with foam PE insulation, an aluminum/mylar heat fusible shield, an aluminum braid shield, an aluminum/mylar/aluminum shield, an aluminum braid and an overall PVC jacket for CATV, Satellite, Broadband and MATV applications 1. Conductor 1.1. AWG & Stranding: 18 AWG Solid 1.2. Material: Copper Covered Steel
| Product | AWG Size & Stranding | Conductor Count | Jacket Thickness | Cable OD | Cable Weight |
|---|---|---|---|---|---|
| AVB3RGB | - | 3 Conductors | - | - | - |
| AVB3RGB | - | 3 Conductors | - | - | - |
| AVB5RGB | - | 5 Conductors | - | - | - |
| AVB6RGB | - | 6 Conductors | - | - | - |
| AVB6RGBC5 | - | 1 conductor | 0.015” | 0.190” | - |
| AVB6RGBC52 | - | 6 Conductors | 0.015” | 0.190” | - |
| AVPRG59CCTV* | 20 AWG Solid | 1 conductor | 0.032” | 0.196” ± 0.006” | 39 Lbs/Mft |
| AVPRG6CATVQ | - | 1 Conductor | 0.019” | 0.258” ± 0.006” | 32 Lbs/Mft |
| AVPRG6CCTV* | - | 1 Conductor | 0.019” | 0.236” ± 0.006” | 43 Lbs/Mft |
| AVRG59CCTV | 20 AWG Solid | 1 conductor | 0.032” | 0.242” ± 0.006” | 39 Lbs/Mft |
| AVRG6CATV | - | - | 0.032” | 0.270” ± 0.005” | 35 lbs/Mft |
| AVRG6CATVQ | - | - | 0.032” | 0.298” ± 0.005” | 41 lbs/Mft |
