AVPRG59CCTV

20 AWG RG59/U constructed with solid bare copper, foamed FEP insulation, a bare copper braid shield and an overall plenum rated PVC jacket. CL2P OR CMP 75’C FT-6 Surveillance Camera cable applications
SKU: AVPRG59CCTV*


• Cable suitable for installations under NEC (NFPA 70) article 800 and article 725 guidelines
• UL listed as type CL2P per UL standard 13 and as type CMP c(UL)us 75°C FT-6 per UL standard 444
• All materials used in the manufacture of this cable are RoHS compliant
• Made in the USA

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.
Products specifications
Attribute nameAttribute value
Conductor
AWG Size & Stranding20 AWG Solid
MaterialAnnealed Bare copper
Conductor Count1 conductor
Standards
Maximum operating voltage300V
Dielectric
MaterialFoamed Fluorinated Ethylene Propylene
Diameter0.135” ± 0.003”
Color CodeNatural
Jacket
MaterialPlenum Rated Polyvinylchloride
Wall Thickness0.032”
Diameter0.196” ± 0.006”
ColorBlack
RipcordN/A
Weight39 Lbs/Mft
Shield
Braid95% Coverage, Bare Copper Braid
Markings
TypeCable permanently identified via surface inkjet print
LegendAVALANCHE(TM) CCTV SURVEILLANCE CAMERA CABLE AVRG59CCTV E171197 20AWG RG59/U 75 OHM (UL) CMP C(UL)US OR (UL) CL2P 75’C FT-6 MADE IN THE USA “ROHS”
Footage MarkersYes

Remember, all of our wire can feature:

  • Short minumum runs
  • Special jacket colors including stripes
  • Custom print legends
  • Custom cable constructions
  • Custom packaging - boxes or reels
  • Custom lengths
  • Your name on package labels
