B202CT

20 AWG 2 conductor 7 strand tinned copper wire with PVC insulation, unshielded and overall PVC jacket for low-voltage electronic cable applications.
SKU: B202CT


• Cable suitable for installation under NEC (NFPA 70) articles 800, 725 and 760 guidelines
• UL listed as CMG c(UL)us per UL standard 444, CL3 per UL standard 13 & FPL per UL standard 1424
• Cable meets RoHS 2002/95/EC Directive, RoHS 2 2011/65/EU Directive, RoHS 3 2015/863/EU Directive
• Cable is REACH compliant per Regulation (EC) No 1907/2006 (224) Updated June 10, 2022
• Operating Voltage: 300V RMS
• Made in the USA

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.
Products specifications
Attribute nameAttribute value
Conductor
AWG Size & Stranding20 AWG 7 Strands Class B
MaterialAnnealed Tinned Copper
Conductor Count2 Conductors
Insulation
MaterialPolyvinylchloride
Wall Thickness0.015”
Color CodeBlack, Red
Assembly
GroundN/A
FillersN/A
BinderN/A
ShieldN/A
Drain WireN/A
Jacket
MaterialPolyvinylchloride
Wall Thickness0.025"
Diameter0.180” ± 0.014”
ColorChrome Gray
RipcordYes
Cold Bend RatingN/A
Weight17 Lbs/Mft
Markings
TypeCable permanently identified via surface inkjet print
LegendLAKE CABLE E171202 20AWG 2C 75C (UL) CL3 SUN RES OR FPL OR C(UL)US CMG FT4 "ROHS COMPLIANT" MADE IN USA
Footage MarkersYes
