| Nominal Electrical Characteristics |
| Impedance | 46 Ω/Mft +/-10% |
| Capacitance | 32.1 pF/ft +/-10% |
| DC Resistance | 2.52 Ω/Mft @ 20°C |
| Conductor |
| AWG Size & Stranding | 14 AWG Solid |
| Material | Bare Copper Wire |
| Conductor Count | 1 Pair |
| AWG & Stranding | 14 Awg Solid |
| Insulation |
| Material | Fluorinated Ethylene Propylene |
| Wall Thickness | .015" |
| Color Code | Black, Red |
| Assembly |
| Nominal Lay Length | 4.50” |
| Shield | Aluminum Mylar Tape Shield - 100% Coverage |
| Drain Wire | 20 Awg 7 Strand Tinned Copper Wire |
| Jacket |
| Material | Fluorinated Ethylene Propylene |
| Thickness | 0.025” |
| Diameter | 0.240” |
| Color | Red |
| Ripcord | Yes |
| Weight | 54 lbs per mft |
| Wall Thickness | .025" |
| Nominal Diameter | .240" |
| Markings |
| Type | Printed Marker Tape |
| Legend | LAKE CABLE P# FF142LL5S E171203-01 14AWG 2C 200C (UL) FPLP FT6 CLASSIFIED NYC CERT FIRE ALARM E-Z STRIP LL39 "ROHS COMPLIANT" MADE IN USA |
| Footage Markers | No |
| Standards |
| Maximum operating voltage | 300V |
| Operating Temperature Range | -70C TO 200C |
| Approvals |
| Approvals List | • Cable suitable for installation under NEC (NFPA 70) article 760 guidelines
• UL listed as type FPLP 200°C per UL standard 1424
• Classified NYC Certified Fire Alarm LL39
• Cable meets RoHS 2002/95/EC Directive, RoHS 2 2011/65/EU Directive, RoHS 3 2015/863/EU Directive
• Cable is REACH compliant per Regulation (EC) No 1907/2006 (223) Updated January 17, 2022
• Maximum Operating Voltage: 300V
• Operating Temperature: -75°C to 200°C
• Made in the USA |
