Picture of IM502142T/19
For representation only. Cable constructions may vary from illustration. Please see spec sheet for complete details.

IM502142T/19

Not what you were looking for?
14 AWG 2 conductor 19 strand tinned copper with PE insulation, shielded with overall PE jacket loop detector lead-in cable, 600V rated, for use in traffic signal installations and suitable for conduit installation in wet or dry locations.
SKU: IM502142T/19

• International Municipal Signal Association 50-2.
• All materials used in the manufacture of this cable are RoHS compliant
• Made in the USA
This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Conductor

AWG Size & Stranding:
14 AWG 19 Strands Class C
Material:
Annealed Tinned Copper
Conductor Count:
2 Conductors

Insulation

Material:
Polyethylene
Wall Thickness:
0.030”
Color Code:
Per IMSA Specification 50-2

Assembly

Lay Length:
Per IMSA Specification 50-2
Shield:
Aluminum/Mylar shield – 100% coverage (Foil facing out)
Drain Wire:
16 AWG 7 strand tinned copper

Jacket

Material:
Polyethylene
Wall Thickness:
0.030”
Diameter:
0.338”
Color:
Black
Ripcord:
Yes
Weight:
62 lbs./Mft.

Markings

Type:
Cable shall be permanently identified via surface printing
Legend:
LAKE CABLE IMSA 50-2 600V 75’C 14AWG (YEAR OF MFG) “ROHS”
Footage Markers:
Yes

Standards

Operating Temperature Range:
-40°C to 75°C
DC Resistance, Nominal:
2.79 Ω/Mft.

Remember, all of our wire can feature:

  • Short minumum runs
  • Special jacket colors including stripes
  • Custom print legends
  • Custom cable constructions
  • Custom packaging - boxes or reels
  • Custom lengths
  • Your name on package labels
