L122PR

12/2PR SOLID BC NS FPLP RED FPLP 150C LL39 NYC

SKU: L122PR

12 AWG 2 PAIR SOLID BARE COPPER WIRE WITH .015" PVDF INSULATION, NON-SHIELDED, OVERALL .025" PVDF RED JACKET.

150'C (UL) FPLP FT-6 CLASSIFIED NYC CERT FIRE ALARM E-Z STRIP LL39 "ROHS COMPLIANT" MADE IN USA

CC: BLACK & RED, WHITE & GREEN

RIPCORD: NO

FOOTAGE MARKERS: YES

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Attribute name	Attribute value
Conductor
AWG Size & Stranding	12 AWG Solid
Material	Bare Copper Wire
Conductor Count	2 Pair
AWG & Stranding	12 Awg Solid
Insulation
Material	Polyvinylidene Fluoride
Wall Thickness	.015"
Color Code	Black & Red, White & Green
Assembly
Pair/ Cable Lay Length	4.50” LHL (2.66 Tw/Ft) 5.00” LHL (2.4Tw/Ft)
Shield	N/A
Drain Wire	N/A
Nominal Lay Length	4.50”
Jacket
Material	Polyvinylidene Fluoride
Wall Thickness	.025"
Diameter	0.382”
Color	Red
Ripcord	No
Weight	122 lbs per mft
Nominal Diameter	.382"
Markings
Type	Permanent Inkjet Surface Print
Legend	LAKE CABLE P# L122PR E171203 12AWG 2PR 150C (UL) FPLP FT6 CLASSIFIED NYC CERT FIRE ALARM E-Z STRIP LL39 “ROHS COMPLIANT” MADE IN USA
Footage Markers	Yes
Standards
Maximum operating voltage	300V
Operating Temperature Range	-40C TO 150C

Copper Price 7/26/2024 4.1050
