L182PR

Conductor

AWG Size & Stranding:

18 AWG Solid

Material:

Bare Copper Wire

Conductor Count:

2 Pair

AWG & Stranding:

18 Awg Solid

Insulation

Material:

Polyvinylidene Fluoride

Wall Thickness:

.015"

Color Code:

Black & Red, White & Green

Assembly

Nominal Lay Length:

4.50”

Cable Lay Length:

6.00”LHL ( 2.0Tw/Ft)

Shield:

N/A

Drain Wire:

N/A

Jacket

Material:

Polyvinylidene Fluoride

Wall Thickness:

.025"

Diameter:

0.283”

Color:

Red

Ripcord:

No

Weight:

47 lbs per mft

Nominal Diameter:

.280"

Markings

Type:

Permanent Inkjet Surface Print

Legend:

LAKE CABLE L182PR E171203 18AWG 2PR 150C (UL) FPLP ALSO CLASSIFIED NYC CERT FIRE ALARM E-Z STRIP LL39 FT6 “ROHS COMPLIANT” MADE IN USA

Footage Markers:

Yes

Standards

Maximum operating voltage:

300V

Operating Temperature Range:

-40C TO 150C

Approvals

Approvals List:

• Cable suitable for installation under NEC (NFPA 70) article 760 guidelines
• UL listed as type FPLP 150°C per UL standard 1424
• Classified NYC Certified Fire Alarm LL39
• Cable meets RoHS 2002/95/EC Directive, RoHS 2 2011/65/EU Directive, RoHS 3 2015/863/EU Directive
• Cable is REACH compliant per Regulation (EC) No 1907/2006 (240) Updated January 23, 2024
• Maximum Operating Voltage: 300V
• Made in the USA
• Operation Temp -40°C to 150°C
• WARNING: This product may contain chemicals, such as Vinyl Chloride, known to the state of California  to cause cancer. For more information, go to www.P65Warnings.ca.gov. Wash hands after handling.
