| Nominal Electrical Characteristics |
| Impedance | 53 Ω |
| Capacitance | 36 pF/ft. |
| Conductor DCR (Max) | 4.15 Ω/Mft. @ 20°C Maximum |
| Conductor |
| AWG Size & Stranding | 16 AWG 19 Strands Class B |
| Material | Bare Copper Wire |
| Conductor Count | 3 |
| AWG & Stranding | 16 Awg 19 Strand |
| Insulation |
| Material | Plenum Rated Polyvinylchloride |
| Wall Thickness | .007" |
| Color Code | Black, Red, White |
| Assembly |
| Nominal Lay Length | 3.00” |
| Shield | N/A |
| Drain Wire | N/A |
| Jacket |
| Material | Black, White, Red, Green, Brown |
| Wall Thickness | Black, White, Red, Green, Brown, Blue |
| Diameter | 0.186” |
| Color | Natural |
| Ripcord | Yes |
| Weight | 35 lbs per mft |
| Nominal Diameter | 0.180” |
| Markings |
| Type | Permanent Inkjet Surface Print |
| Legend | LAKE CABLE E171202 16AWG 3C 75°C (UL) CL3P OR FPLP OR C(UL)US CMP FT-6 “ROHS COMPLIANT” MADE IN USA |
| Footage Markers | Ascending/Descending |
| Standards |
| Recommended Operating Voltage | 300V |
| Maximum operating voltage | 300V |
| Operating Temperature Range | -20C TO 75C |
| Approvals |
| Approvals List | • Cable suitable for installation under NEC (NFPA 70) articles 800, 725 and 760 guidelines
• Cable suitable for installation in Canada under Section 60 of CEC, Part I
• C(UL)US listed as CMP per UL standard 444 and per CSA C22.2 No. 214-17
• UL listed as CL3P per UL standard 13 or FPLP per UL standard 1424
• Cable meets NFPA 262 (Steiner tunnel) flame test
• Cable meets RoHS 2002/95/EC Directive, RoHS 2 2011/65/EU Directive, RoHS 3 2015/863/EU Directive
• Cable is REACH compliant per Regulation (EC) No 1907/2006 (224) Updated June 10, 2022
• Operating Voltage: 300V RMS
• Made in the USA
• WARNING: This product may contain chemicals, such as Vinyl Chloride, known to the state of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. Wash hands after handling. |
