P164CS

16 AWG 4 conductor 19 strand bare copper wire, plenum rated PVC insulation, shielded, with an overall plenum rated PVC jacket

SKU: P164CS

• Refer to NEC (NFPA 70) article 725 and article 800 for installation guidelines
• UL listed as type CL3P per UL standard 13 and as type CMP c(UL)us 75°C FT-6 per UL standard 444
• All materials used in the manufacture of this cable are RoHS compliant
• Made in the USA

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Attribute name	Attribute value
Conductor
AWG Size & Stranding	16 AWG 19 Strands Class C
Material	Annealed Bare Copper
Conductor Count	4 Conductors
Insulation
Material	Plenum Rated Polyvinylchloride
Wall Thickness	0.007”
Color Code	Black, Red, White, Green
Assembly
Nominal Lay Length	2.75” LHL (4.3 Tw/Ft)
Shield	Aluminum Mylar Tape – 100% Coverage
Drain Wire	24 AWG 7 Strand Tinned Copper
Jacket
Material	Plenum Rated Polyvinylchloride
Wall Thickness	0.015”
Diameter	0.206”
Color	Natural
Ripcord	Yes
Weight	48 Lbs/Mft
Markings
Type	Cable shall be permanently identified via surface inkjet print
Legend	LAKE CABLE E171202 16AWG 4C (UL) CMP C(UL)US or (UL) CL3P 75’C FT-6 “ROHS”
Footage Markers	Yes
Standards
Maximum Voltage	300V
