Conductor |
AWG Size & Stranding | 22 AWG 7 Strands Class B |
Material | Annealed Bare Copper |
Conductor Count | 12 Conductors |
Insulation |
Material | Plenum Rated Polyvinylchloride |
Wall Thickness | 0.007” |
Color Code | Black, Red, White, Green, Brown, Blue, Orange, Yellow, Violet, Gray, Pink, Tan |
Assembly |
Nominal Lay Length | 3.00” LHL (4.0 Tw/Ft) |
Shield | Aluminum Mylar Tape – 100% Coverage |
Drain Wire | 24 AWG 7 Strand Tinned Copper |
Jacket |
Material | Plenum Rated Polyvinylchloride |
Wall Thickness | 0.015” |
Diameter | 0.209” |
Color | Natural |
Ripcord | Yes |
Weight | 43 Lbs/Mft |
Markings |
Type | Cable shall be permanently identified via surface inkjet |
Print Legend | LAKE CABLE E171202 22AWG 12C (UL) CMP C(UL)US OR (UL) CL3P 75’C FT-6 “ROHS” |
Footage Markers | Yes |
Standards |
Maximum Voltage | 300V |
