P223CS

22/3C 7XBC OAS CMP/CL3P/FPLP NATURAL

SKU: P223CS

22 AWG 3C 7 STRAND BARE COPPER WIRE WITH .007" SGPVC INSULATION, OVERALL ALUMINUM MYLAR TAPE SHIELD WITH A 24 AWG 7 STRAND TINNED COPPER DRAIN WIRE, OVERALL .015" NATURAL SGPVC JACKET.

75'C (UL) CL3P OR FPLP OR C(UL)US CMP FT-6 "ROHS COMPLIANT" MADE IN USA

CC: BLACK, RED, WHITE

RIPCORD: YES

FOOTAGE MARKERS: YES

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Attribute name	Attribute value
Conductor
AWG Size & Stranding	22 AWG 7 Strands Class B
Material	Bare Copper Wire
Conductor Count	3
AWG & Stranding	22 Awg 7 Strand
Insulation
Material	Plenum Rated Polyvinylchloride
Wall Thickness	.007"
Color Code	Black, Red, White
Assembly
Nominal Lay Length	3.00”
Shield	Aluminum Mylar Tape Shield - 100% Coverage
Drain Wire	24 Awg 7 Strand Tinned Copper Wire
Jacket
Material	Plenum Rated Polyvinylchloride
Wall Thickness	.015"
Diameter	0.124”
Color	Natural
Ripcord	Yes
Weight	13 lbs per mft
Nominal Diameter	0.122”
Markings
Type	Permanent Inkjet Surface Print
Print Legend	LAKE CABLE E171202 22AWG 3C (UL) CMP C(UL)US OR (UL) CL3P 75’C FT-6 “ROHS”
Footage Markers	Ascending/Descending
Legend	LAKE CABLE E171202 22AWG 3C 75C (UL) CL3P OR FPLP OR C(UL)US CMP FT6 “ROHS COMPLIANT” MADE IN USA
Standards
Maximum Voltage	300V
Maximum operating voltage	300V
Operating Temperature Range	-20C TO 75C

Copper Price 7/26/2024 4.1050
