Found 29 products.
Sort by
Display per page
1/0 AWG 3C 19STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
1/0 AWG 4C 19STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
2/0 AWG 3C 19STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
2/0 AWG 4C 19STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
2 AWG 3C 7STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
2 AWG 4C 7STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
4/0 AWG 3C 19STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
4/0 AWG 4C 19STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
4 AWG 3C 7STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
4 AWG 4C 7STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
6 AWG 3C 7STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
6AWG 4C 7STR TC + UNINS GND NS XLPE/LSZH (UL) TC-ST1-ER 600V 90C
| Product | AWG Size & Stranding | Conductor Count | Jacket Thickness | Cable OD | Cable Weight |
|---|
| VGXH1/03T | 1/0 AWG 19 Strand | 3 | 0.080" | 1.202" | 1468 lbs/Mft |
| VGXH1/04T | 1/0 AWG 19 Strand | 4 | 0.080" | 1.328" | 1865 lbs/Mft |
| VGXH2/03T | 2/0 AWG 19 Strand | 3 | 0.080" | 1.273" | 1742 lbs/Mft |
| VGXH2/04T | 2/0 AWG 19 Strand | 4 | 0.080" | 1.407" | 2232 lbs/Mft |
| VGXH23T | 2 AWG 7 Strand | 3 | 0.080" | 0.989" | 995 lbs/Mft |
| VGXH24T | 2 AWG 7 Strand | 4 | 0.080" | 1.100" | 1262 lbs/Mft |
| VGXH4/03T | 4/0 AWG 19 Strand | 3 | 0.080" | 1.542" | 2634 lbs/Mft |
| VGXH4/04T | 4/0 AWG 19 Strand | 4 | 0.110" | 1.768" | 3520 lbs/Mft |
| VGXH43T | 4 AWG 7 Strand | 3 | 0.060" | 0.803" | 639 lbs/Mft |
| VGXH44T | 4 AWG 7 Strand | 4 | 0.080" | 0.933" | 852 lbs/Mft |
| VGXH63T | 6 AWG 7 Strand | 3 | 0.060" | 0.721" | 463 lbs/Mft |
| VGXH64T | 6 AWG 7 Strand | 4 | 0.060" | 0.786" | 579 lbs/Mft |
