Found 104 products.
Sort by
Display per page
10AWG 4C 7STR BC + INS GND VNTC NS (UL) TC-ER 600V 90C
12AWG 2C 7STR BC + INS GND NS VNTC (UL) TC-ER 600V 90C
12AWG 3C 7STR BC + INS GND NS VNTC (UL) TC-ER 600V 90C
12AWG 4C 7STR BC + INS GND NS VNTC (UL) TC-ER 600V 90C
14AWG 3C 7STR BC + INS GND NS VNTC (UL) TC-ER-JP 600V 90C
4AWG 3C 7STR BC + INS GND NS VNTC (UL) TC-ER -JP 600V 90C
6AWG 3C 7STR BC + INS GND NS VNTC (UL) TC-ER-JP 600V 90C
8AWG 4C 7STR BC + INS GND NS VNTC (UL) TC-ER 600V 90C
| Product | AWG Size & Stranding | Conductor Count | Jacket Thickness | Cable OD | Cable Weight |
|---|
| VIG104 | 10 AWG 7 Strand Class B | 4 | .060" | 0.566” | 264 lbs./Mft |
| VIG122/M1 | 12 AWG 7 Strand Class B | 2 | .045" | - | 105 lbs./Mft |
| VIG123 | 12 AWG 7 Strand Class B | 3 | .045" | - | 133 lbs./Mft |
| VIG124 | 12 AWG 7 Strand Class B | 4 | .045" | - | 162 lbs./Mft |
| VIG143 | 14 AWG 7 Strand Class B | 3 | .045" | - | 95 lbs./Mft |
| VIG43 | 4 AWG 7 Strand Class B | 3 | .060" | 0.895” | 674 lbs./Mft |
| VIG63/M4 | 6 AWG 7 Strand Class B | 3 | .060" | - | 459 lbs./Mft |
| VIG84/M4 | 8 AWG 7 Strand Class B | 3 | .060" | - | 397 lbs./Mft |
