12 AWG 2 conductor 19 strand tinned copper with PE insulation, shielded with overall PE jacket loop detector lead-in cable, 600V rated, for use in traffic signal installations and suitable for conduit installation in wet or dry locations.
14 AWG 2 conductor 19 strand tinned copper with PE insulation, shielded with overall PE jacket loop detector lead-in cable, 600V rated, for use in traffic signal installations and suitable for conduit installation in wet or dry locations.
16 AWG 2 conductor 19 strand tinned copper with PE insulation, shielded with overall PE jacket loop detector lead-in cable, 600V rated, for use in traffic signal installations and suitable for conduit installation in wet or dry locations.
18 AWG 2 conductor 19 strand tinned copper with PE insulation, shielded with overall PE jacket loop detector lead-in cable, 600V rated, for use in traffic signal installations and suitable for conduit installation in wet or dry locations.
12 AWG 1 conductor 7 strand bare copper with XLPE insulation, unshielded suitable for use in saw cuts as an inductance loop detector or in conduit as a lead-in wire, 600V rated.
14 AWG 1 conductor 7 strand bare copper with XLPE insulation, unshielded suitable for use in saw cuts as an inductance loop detector or in conduit as a lead-in wire, 600V rated.
14 AWG 1 conductor 19 strand bare copper with PVC/NYLON insulation, conductor loosely encased in either a PVC tube jacket, rated at 600V and suitable for use as an inductance loop detector wire.
14 AWG 1 conductor 19 strand bare copper with PVC/NYLON insulation, conductor loosely encased in either a PE tube jacket, rated at 600V and suitable for use as an inductance loop detector wire.
14 AWG 1 conductor 19 strand bare copper with PVC/NYLON insulation, conductor loosely encased in either a PVC tube jacket, rated at 600V and suitable for use as an inductance loop detector wire.
14 AWG 1 conductor 19 strand bare copper with PVC/NYLON insulation, conductor loosely encased in either a PE tube jacket, rated at 600V and suitable for use as an inductance loop detector wire.
14 AWG 1 conductor 19 strand bare copper with XLPE insulation, conductor loosely encased in either a PVC tube jacket, rated at 600V and suitable for use as an inductance loop detector wire.
14 AWG 1 conductor 19 strand bare copper with XLPE insulation, conductor loosely encased in either a PE tube jacket, rated at 600V and suitable for use as an inductance loop detector wire.
| Product | AWG Size & Stranding | Conductor Count | Jacket Thickness | Cable OD | Cable Weight |
|---|---|---|---|---|---|
| IM502122T/19 | 12 AWG 19 Strands Class C | 2 Conductors | 0.030” | 0.363” | 80 lbs./Mft. |
| IM502142T/19 | 14 AWG 19 Strands Class C | 2 Conductors | 0.030” | 0.338” | 62 lbs./Mft. |
| IM502162T/19 | 16 AWG 19 Strands Class C | 2 Conductors | 0.030” | 0.302” | 45 lbs./Mft. |
| IM502182T/19 | 18 AWG 19 Strands Class C | 2 Conductors | 0.030” | 0.276” | 37 lbs./Mft. |
| IM513121/7 | 12 AWG 7 Strands Class B | 1 Conductor | N/A | 0.152” | 41 lbs./Mft. |
| IM513141/7 | 14 AWG 7 Strands Class B | 1 Conductor | N/A | 0.133” | 20 lbs./Mft. |
| IM515141/19 | 14 AWG 19 Strands Class C | 1 Conductor | 0.030” +/- 0.005” | - | 30 lbs./Mft. |
| IM515141/19-00PE | 14 AWG 19 Strands Class C | 1 Conductor | 0.030” +/- 0.005” | - | 26 lbs./Mft. |
| IM515141/19-03 | 14 AWG 19 Strands Class C | 1 Conductor | 0.030” +/- 0.005” | - | 30 lbs./Mft. |
| IM515141/19-03PE | 14 AWG 19 Strands Class C | 1 Conductor | 0.030” +/- 0.005” | - | 26 lbs./Mft. |
| IM517141/19 | 14 AWG 19 Strands Class C | 1 Conductor | 0.030” +/- 0.005” | - | 33 lbs./Mft. |
| IM517141/19-00PE | 14 AWG 19 Strands Class C | 1 Conductor | 0.030” +/- 0.005” | - | 29 lbs./Mft. |
