8AWG 3C 7STR BC OAS VNTC (UL) TC-ER 600V 90C

SKU: V83S/M4

8 AWG 3C 7 STRAND BARE COPPER WIRE

WITH .030" PVC & .006" NYLON INSULATION,

FILLERS AND OVERALL CLEAR MYLAR WRAP TAPE,

OVERALL ALUMINUM MYLAR ATPE SHIELD WITH A

12 AWG 7 STRAND TINNED COPPER DRAIN WIRE,

OVERALL .060" BLACK PVC JACKET.

(UL) TC-ER-JP-JP 600V 90'C DRY 75'C WET

SUN RES DIR BUR OIL RES I FT-4 "ROHS"

CC: METHOD 4, BLACK AND NUMBERED

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.

Products specifications

Attribute name	Attribute value
Jacketing
Ripcord	Yes
Conductor
AWG Size & Stranding	8 AWG 7 Strand Class B
Material	Bare Copper Wire
Conductor Count	3
Insulation
Material	Polyvinylchloride/Nylon
Wall Thickness	0.030" PVC, 0.006" Nylon
Color Code	Method 4, Black and Numbered
Assembly
Nominal Lay Length	7.5"
Shield	Aluminum Mylar Tape
Drain Wire	12 AWG 7 Strand Tinned Copper
Jacket
Material	Polyvinylchloride
Wall Thickness	.060"
Color	Black
Outside Diameter	.585"
Weight	298 lbs./Mft
Markings
Type	Permanent Inkjet Surface Print
Legend	LAKE CABLE E208309 8AWG 3C (UL) TC-ER-JP-JP 600V 90'C DRY 75'C WET SUN RES DIR BUR OIL RES I FT-4 "ROHS" MADE IN USA
Footage Markers	Ascending/Descending
Standards
Maximum Voltage	600V
Operating Temperature Range	90C
Approvals
Approvals List	• Refer to NEC (NFPA 70) article 1277 for installation guidelines • Cable is suitable for use in Class I Division II hazardous locations • Individual conductors pass UL VW-1 flame test, rated THHN/THWN/VW-1 • UL listed as Type TC-ER per UL Standard 1277 for tray cables • UL approved for Direct Burial, Sunlight and Oil I Resistant applications • Cable meets UL 1581 & 1202 (FT-4) 70,000 BTU/HR & ICEA T-29-520 210,000 BTU/HR requirements • Meets ICEA S-73-532, where applicable • All materials used in the manufacture of this cable are RoHS compliant • Made in the USA

Copper Price 04/30/2025 4.5070
