224C

22 AWG 4 conductor 7 strand bare copper wire with PVC insulation, unshielded and overall PVC jacket for low-voltage electronic cable applications.
SKU: 224C


• Refer to NEC (NFPA 70) article 725 and article 800 for installation guidelines
• UL listed as type CL3R per UL standard 13 and as type CMR c(UL)us 75°C per UL standard 444
• All materials used in the manufacture of this cable are RoHS compliant
• Made in the USA

This spec is for informational purposes and subject to change. This spec may not be suitable for submission. Contact Lake Cable for non-watermark spec sheet.
Products specifications
Attribute nameAttribute value
Conductor
AWG Size & Stranding22 AWG 7 Strands Class B
MaterialAnnealed Bare Copper
Conductor Count4 Conductors
Standards
Recommended Operating Voltage300V
Jacket
MaterialPolyvinylchloride
Wall Thickness0.015”
Diameter0.139”
ColorGray
RipcordYes
Weight16 Lbs/Mft
Assembly
Nominal Lay Length3.00” LHL (4.0 Tw/Ft)
ShieldN/A
Drain WireN/A
Insulation
MaterialPolyvinylchloride
Wall Thickness0.007”
Color CodeBlack, Red, White, Green
Markings
TypeCable permanently identified via surface inkjet print
LegendLAKE CABLE E171197 22AWG 4C (UL) CMR C(UL)US OR (UL) CL3R 75’C SUN RES FT-4 “ROHS”
Footage MarkersYes

Remember, all of our wire can feature:

  • Short minumum runs
  • Special jacket colors including stripes
  • Custom print legends
  • Custom cable constructions
  • Custom packaging - boxes or reels
  • Custom lengths
  • Your name on package labels
