Found 72 products.
Sort by
Display per page
12AWG 12C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
10AWG 12C 19STR BC OAS VNTC (UL) TC-ER 600V 90C
18AWG 9C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
18GA 7C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
18GA 6C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
18AWG 5C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
18AWG 4C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
18GA 3C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
18AWG 2C 7STR BC OAS VNTC (UL) TC 600V 90C
16AWG 9C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
16AWG 8C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
16AWG 7C 7STR BC OAS VNTC (UL) TC-ER 600V 90C
| Product | AWG Size & Stranding | Conductor Count | Jacket Thickness | Cable OD | Cable Weight |
|---|
| V1212S | 12 AWG 7 Strand Class B | 12 | .060" | 0.687” | 391 lbs./Mft |
| V1012S | 10 AWG 7 Strands Class B | 12 Conductors | 0.080” | 0.857” | 642 lbs./Mft. |
| V189S | 18 AWG, 7 Strands Class B | 9 Conductors | 0.045” | 0.408” | 110 lbs./Mft. |
| V187S | 18 AWG, 7 Strands Class B | 7 Conductors | 0.045” | 0.358” | 89 lbs./Mft. |
| V186S | 18 AWG, 7 Strands Class B | 6 Conductors | 0.045” | 0.341” | 80 lbs./Mft. |
| V185S | 18 AWG, 7 Strands Class B | 5 Conductors | 0.045” | 0.331” | 71 lbs./Mft. |
| V184S | 18 AWG, 7 Strands Class B | 4 Conductors | 0.045” | 0.298” | 60 lbs./Mft. |
| V183S | 18 AWG, 7 Strands Class B | 3 Conductors | 0.045” | 0.273” | 49 lbs./Mft. |
| V182S | 18 AWG, 7 Strands Class B | 2 Conductors | 0.045” | 0.263” | 41 lbs./Mft. |
| V169S | 16 AWG, 7 Strands Class B | 9 Conductors | 0.045” | 0.453” | 148 lbs./Mft. |
| V168S | 16 AWG, 7 Strands Class B | 8 Conductors | 0.045” | 0.420” | 134 lbs./Mft. |
| V167S | 16 AWG, 7 Strands Class B | 7 Conductors | 0.045” | 0.398” | 120 lbs./Mft. |
